Hall effect sensor BJHCS-SH-1000A
Hall effect current sensor Closed loop – Ipn = 1000A Vc = ±15 … ±24V Vout = 200 mA – Primary through hole, secondary on PCB – Hole diameter 40,5 mm
ADDITIONAL INFORMATION
Additional information
| fiche-technique | BJHCS-SH-1000A |
|---|---|
| mounting | Primary through hole, secondary on PCB |
| output-type | Current |
| nominal-primary-current-a | 1000 |
| max-primary-current-a | 2000 |
| supply-voltage-v | ±15 … ±24 |
| type | |
| nominal-output-value | 200 mA |
| accuracy | 0.2 |
